180mm (7 inch) Carbon Steel Weld on Hinge

From: £14.50 + VAT

180mm x 22mm carbon steel hinge, complete with a brass washer.
Also available with optional grease function.
Recommended weight per pair: 650 Pounds / 295 kg

*The weights are for comparison purposes only, environmental applications may effect these figures.

Ideal uses:

  • Metal shutters
  • Metal hatches
  • Ship doors (not marine grade)
SKU: N/A Category:
Bulk order discounts
Over 10 hinges - 20% discount
Over 25 hinges - 40% discount
Over 100 hinges - 50% discount

Additional information

Hinge Material

Carbon Steel

Weight

505g

Length

180mm

Diameter

22mm

Depth

24mm

Grease Function

No, Yes

Pin Material

Carbon Steel

Pin Length

38mm

Pin Diameter

12mm

Washer

Brass
